Standard Features
JFT
Models
Flight Machine
FLIGHT
Project
Item
Quantity
CSI Section 11400
Approval
Date
Uses 140 gallons (530 ltrs) of water per hour with sanitizing
hot water rinse
All tanks and hoods constructed from 16 gauge 304 stainless
steel with a No. 3 finish and heliarced welded
Stainless steel frame, legs and feet
Two tank rackless conveyor shall have a maximum capacity
of 17,101 dishes per hour at an NSF rated belt speed of 8.63
feet per minute. At 6.4 feet (2 m) per minute capacity will be
12,726 dishes per hour.
Belt width of 29” (737 mm) and a maximum clearance of 25”
(635 mm) throughout the machine
Enclosure panels, hood and doors are stainless steel and dou-
ble wall insulated to reduce heat dissipation, outside surface
temperatures, and noise pollution
Insulated access doors for removal, cleaning and servicing
V-shape tank(s) design to increase visibility and accessibility
for cleaning as well as insure complete tank draining
Heated power rinse zone uses fresh rinse water a second
time to provide pristine results
A sequential digital temperature readout of each tank
housed in the door of the electrical control panel. The read-
outs will constantly display the temperature of the prewash,
wash, power rinse and final rinse in 5 second intervals
A ball valve in the drain line of each tank and interconnected
to a common machine drain connection at the load end of
the machine
Each tank will be automatically filled and maintained by a
water level float. Water will be automatically added to the
machine when required
•
•
•
•
•
•
•
•
•
•
•
•
Highway 25E
P. O. Box 1060
Barbourville, KY 40906
Tel: 606-523-9795
Tel: 1-888-800-5672
Fax: 606-523-9196
E-mail: info@jacksonmsc.com
www.jacksonmsc.com
07610-002-85-11 (8/07)
Block manifold wash arms are easy to remove, clean, and
replace with non-clogging convex wash arm jets
Large, removable scrap screens
Self draining stainless steel pumps, impellers, and hous-
ings are readily accessible and serviceable
Conveyor belt drive operates at two speeds and is pro-
tected by an overload safety device and an automatic
shut-down actuator
Each door is equipped with a door safety switch to pre-
vent it from running when the door(s) are open. If a door
is opened during operation the switch will immediately
shut down the machine
Operator activated start-stop switches on both the load
and unload ends and the control panel
Removable insulated panels to enclose the unit down
to the base frame on both the front and rear of the
machine
A single, built-in 18” (457 mm) diameter indirect vent
connection with a 0.19 HP exhaust fan mounted in a
cleanable cross duct on the machine for condensate
removal and indirect vent connection
3” minimum wall clearance
Service access from front of machine
•
•
•
•
•
•
•
•
•
•
Options
Blower dryer
Additional wash section
Additional load module
Additional unload module
25’ (8 m) wash down
hose - mounted
Electrical connection with
circuit breakers
Dual point electrical connection
Low profile doors
Flanged feet
Multiple conveyor peg choice
Drain at load or unload end
