11
3. Move the tines to the left to make room for larger dishes.
Move the tines to the right to wedge plastic or other
lightweight items against the side of the rack.
No-flip clips
The no-flip clips hold lightweight plastic items such as cups, lids,
or bowls in place during washing.
To move a clip
1. Pull the clip up and off the tine.
2. Reposition the clip on another tine.
Loading Bottom Rack
The bottom rack is designed for plates, pans, casseroles, and
utensils. Many items, up to 13" (33 cm) tall, fit in the bottom rack.
(See recommended loading patterns shown.)
NOTE: The features on your dishwasher rack may vary from the
drawings shown.
■ Do not load glasses, cups, or lightweight plastic items in the
bottom rack. Load small items in the bottom rack only if they
are secured in place.
■ Load plates, soup bowls, etc., between tines.
■ Overlap the edges of plates for large loads.
■ Load soup, cereal, and serving bowls in the rack in a variety
of ways depending upon their size and shape. Load bowls
securely between the rows of tines. Do not nest bowls
because the spray will not reach all surfaces.
■ Load cookie sheets, cake pans, and other large items at the
sides and back. Loading such items in front can keep the
water spray from reaching the detergent dispenser.
■ Secure heavily soiled cookware face down in the rack. If
using TURBOZONE™ wash option, load cookware in
T
URBOZONE™ wash area. (See “TURBOZONE™ wash area.”)
■ Make sure pot handles and other items do not stop rotation
of the spray arm(s). The spray arm(s) must move freely.
■ Do not load items between the bottom rack and the side of
the dishwasher tub because they might block the water inlet
opening.
TURBOZONE™ wash area
The TURBOZONE™ wash area is located at the back of the lower
dishrack.
NOTE: You must select the TURBOZONE™ wash option to utilize
this wash feature. Do not face items toward the rear of the unit if
you are not using this wash option.
■ Load pans, casserole dishes, etc. in the back of the lower
dishrack with the soiled surfaces facing the T
URBOZONE™
spray jets. Make sure items do not interfere with the water
feed tube, spray arms, or T
URBOZONE™ spray jets.
■ Tip items toward the rear of the unit between the back two
rows of tines to maximize coverage.
IMPORTANT: Only one row of items may face the
T
URBOZONE™ spray jets. Load items so they do not interfere
with the rotation of the T
URBOZONE™ spray jets. Stacking,
overlapping, or nesting items will keep the TURBOZONE™
spray jets from reaching all of the surfaces.
10 place setting
12 place setting
TURBOZONE™ wash area
T
URBOZONE™ wash area side view
