Beyond the Basics
specifications
Input Sensitivity/Impedance:
DJ MIC (XLR jack) ..........................1.5 mV, 600 ohms, Balanced/Unbalanced
MIC 2 (PHONE jack) .......................1.5 mV, 600 ohms, Balanced/Unbalanced
PHONO 1, PHONO 2 ............................................................... 3 mV/50 kOhms
LINE 1, LINE 2, LINE 3, LINE 4 ............................................ 150 mV/10 kOhms
Output Level:
Main Out ..................................................................................... 2V/10 kOhms
Record ................................................................................. 150 mV/10 kOhms
Frequency Response .............................................................20–20K Hz ±3dB
S/N Ratio (for 1 kHz):
MIC .............................................................................................................60dB
PHONO ......................................................................................................70dB
LINE ...........................................................................................................80dB
Distortion:
MIC ..........................................................................................................0.20%
PHONO ....................................................................................................0.07%
LINE ......................................................................................................... 0.05%
Tone Control (MIC):
TREBLE ..................................................................................................±10dB
BASS ......................................................................................................±10dB
Equalizer Control:
Control Frequencies ............................
60, 150, 400, 1k, 2.4k, 6k, and 15k Hz
Boost/Cut Range ................................................................±12dB from center
Talkover Attenuation ............................................................................. –16dB
Power Source ..............................................................AC 120V, 60Hz, 20Watt
Dimensions .................................................................19 x 38/1 x 9
7
/
16
Inches
(482 x 79 x 240 mm WHD)
Weight ...................................................................................
9.92 lbs (4.5 kgs)
Specifications are typical; individual units might vary. Specifications are
subject to change and improvement without notice.
