DIGITAL FABRIC STEAM PRESS PRODUCT
INFORMATION
6
Top Innovations, Inc.
- The Handle (1) is used to safely lift up and lower the Pressing Plate, and carry the
unit.
- The Steam Burst Buttons (2) are located on either side of the Handle, and
produce a powerful burst of steam when pressed.
- The Water Reservoir Cap (3a) covers the Water Reservoir fill hole and must be
removed in order to fill the Water Reservoir with distilled water.
- The Water Reservoir (3b) is the tank in which distilled water is stored for use by
the unit. There must be water in the Water Reservoir in order for the units steam
burst function to work correctly.
- The Ironing Board (4) is the padded surface onto which fabric is placed during
pressing. The fabric cover is removable and can be washed.
- The Pressing Plate (5) is the temperature-controlled teflon surface that heats and
presses fabric.
- The Pressing Plate Cover (6) is the stainless-steel cover that protects the Pressing
Plate.
- The On/Off Switch (7) activates and deactivates the unit.
- The Locking Knob (8) locks the Pressing Plate and Ironing Board together. This
allows for carrying and storage of the unit.
- The Power Indicator Light (Red) (9) illuminates when the On/Off Switch is set to
the “On” position, providing you with a clear visual indication that the unit is
powered on.
- The Pressing Indicator Light (Green) (10) illuminates while the unit is heating to
the selected temperature. When deactivated, this indicates that you are ready to
press.
- The Steam Burst Ready Indicator Light (Yellow) (11) illuminates once the unit is
ready to produce bursts of steam, providing you with a clear visual indication that
you can begin using the Steam Burst Buttons.
- The Temperature Control Buttons (12) are pushed to select a desired temperature.
Press the right arrow button to cycle right through the list of fabric choices above
the buttons, and press the left arrow button to cycle left through the list of fabric
choices above the buttons.
- The Cord Storage Compartment (13) provides a convenient and easily accessible
place to store the power cord.
- The Measuring Cup (14) is designed to assist you in easily filling the Water
Reservoir with distilled water.
- The Spray Bottle (15) allows you to moisten fabrics before pressing, which helps
to make the pressing process easier and more effective in certain instances.
- The Pressing Cushion (16) is a fabric-covered pad used for pressing gathered or
contoured areas such as sleeves, darts, or yokes.
