4
REFRIGERATOR
INSTALLATION
Unpacking
Removing Packaging Materials
■
Remove tape and glue from your refrigerator before using. To
remove any remaining tape or glue, rub the area briskly with
your thumb. Tape or glue residue can also be easily removed
by rubbing a small amount of liquid dish soap over the
adhesive with your fingers. Wipe with warm water and dry.
■
Do not use sharp instruments, rubbing alcohol, flammable
fluids, or abrasive cleaners to remove tape or glue. These
products can damage the surface of your refrigerator. For
more information, see “Refrigerator Safety” section.
■
On some models, shelves, bins, door shelf rails, and other
feature parts may be packaged in the Interior FeaturePak.
Follow the instructions contained in the package for proper
assembly.
IMPORTANT:
Do not remove the white foam air return insert that
is located behind the control panel on the ceiling of the
refrigerator (on some models). The insert is part of the refrigerator
and not part of the packing material. If the insert is removed, ice
may migrate down from the freezer and cause icicles to form.
Location Requirements
To ensure proper ventilation for your refrigerator, allow for
¹⁄₂
in.
(1.25 cm) space on each side and at the top. When installing your
refrigerator next to a fixed wall, leave 2 in. (5.08 cm) minimum on
each side (depending on your model) to allow for the door to
swing open. If your refrigerator has an ice maker, allow extra
space at the back for the water line connections.
NOTE:
Do not install the refrigerator near an oven, radiator, or
other heat source, nor in a location where the temperature will fall
below 55˚F (13˚C).
Electrical Requirements
Before you move your refrigerator into its final location, it is
important to make sure you have the proper electrical
connection:
Recommended Grounding Method
Plug 1: A 115 Volt, 60 Hz., AC only 15 or 20 ampere fused,
grounded (earthed) electrical supply is required.
Plugs 2 and 3: A 220/240 Volt/50 Hz or 220 Volt/60Hz AC only 10
ampere fused and grounded (earthed) electrical supply is
required.
It is recommended that a separate circuit serving only your
refrigerator be provided. Use an outlet that cannot be turned off
by a switch. Do not use an extension cord.
WARNING
Excessive Weight Hazard
Use two or more people to move and install
refrigerator.
Failure to do so can result in back or other injury.
WARNING
Explosion Hazard
Keep flammable materials and vapors, such as
gasoline, away from refrigerator.
Failure to do so can result in death, explosion,
or fire.
1
/
2" (1.25 cm)
2" (5.08 cm)
WARNING
Electrical Shock Hazard
Plug into a grounded (earthed) outlet.
Failure to follow these instructions can result in
death, fire, or electrical shock.
Do not use an extension cord.
Do not use an adapter.
Do not remove ground prong.
Plug 1
Plug 2
Plug 3
