Table A-14. Part No. Reference Table (Continued)
Ref.No. Description PPL Name
520
REAR PAPER GUIDE PAPER GUIDE ASSY., REAR
521
PF ROLLER SUPPORT ROLLER, PF, SUPPORT
522
PF HOLDER SUPPORT HOLDER, PF, SUPPORT
523
TORSION SPRING, 5800 TORORSION SPRING, 5800
524
PE HARNESS HARNESS, PE
525
PF STEPPING MOTOR STEPPING MOTOR, PF
526
HP DETECTOR DETECTOR, HP
527
HP HARNESS HARNESS, HP
528
PUMP B PUMP ASSY.; B
529
UPPER YMC CAP POROUS PAD POROUS PAD, CAP, YMC, UPPER
530
LOWER YMC CAP POROUS PAD POROUS PAD, CAP, YMC, LOWER
531
UPPER BK CAP POROUS PAD POROUS PAD, CAP, BK, UPPER
532
LOWER BK CAP POROUS PAD POROUS PAD, CAP, BK, LOWER
533
ASP HEAD CLEANER CLEANER, HEAD, ASP
534
CLEANER LEVER LEVER, CLEANER
535
DRIVEN ROLLER HOLDER C HOLDER, ROLLER, DRIVEN; C
536
CR GUIDE SHAFT SHAFT, CR, GUIDE
537
OIL PAD OIL PAD
538
KNOB LEVER LEVER, KNOB
539
CR STEPPING MOTOR (.4.0 VDC, 0.4 A) STEPPING MOTOR, CR (DC.4.0V,0.4A)
540
CR COVER B COVER ASSY., CR; B
541
CR GUIDE GROUNDING SPRING GROUNDING SPRING, CR, GUIDE
542
CR STOPPER LEVER LEVER, CR, STOPPER
543
CR DAMPER DAMPER, CR
544
CR DAMPER SHAFT B SHAFT, DAMPER, CR; B
545
PAPER LOAD LEVER LEVER, PAPER LOAD
546
DRIVEN ROLLER ROLLER, DRIVEN
547
DRIVEN ROLLER HOLDER HOLDER, ROLLER, DRIVEN
548
DRIVEN ROLLER C ROLLER, DRIVEN; C
549
DRIVEN PULLEY LEVER LEVER ASSY., PULLEY, DRIVEN
550
PARALLEL ADJUST BUSHING BUSHING, PARALLEL, ADJUST
551
DRIVEN ROLLER SUPPORT ROLLER, DRIVEN, SUPPORT
552
SUB FRAME FRAME ASSY., SUB
553
PAPER EJECT HOLDER HOLDER ASSY., PAPER EJECT
554
PAPER EJECT HOLDER, B HOLDER ASSY., PAPER EJECT; B
555
PAPER EJECT FRAME FRAME, PAPER EJECT
556
PAPER EJECT ROLLER ROLLER ASSY., PAPER EJECT
557
PAPER EJECT CLUTCH CLUTCH PAPER EJECT
558
EDGE GUIDE SLIDER SLIDER, EDGE GUIDE
559
BUSHING 6 mm BUSHING, 6
560
HEAD FASTENING PRESSURE PLATE PRESSINGPLATE, FASTEN, HEAD
Stylus Pro XL Appendix
Rev. A A-23
