Introduction
When shooting with the viewfinder, the following information
appears in the viewfinder.
t Memo
• The information is displayed in the viewfinder when 0
is pressed halfway, or during the meter operating time
(default setting: 10 sec.).
• The AF point in use for autofocus appears in red
(Superimpose AF Area) when 0 is pressed halfway.
You can set it to [Off] in [16 Superimpose AF Area] of the E3
menu.
• You can adjust the image
sharpness in the viewfinder using
the diopter adjustment lever. If it is
difficult to move the diopter
adjustment lever, lift up and
remove the eyecup. Adjust the
diopter setting until the AF frame in
the viewfinder looks sharp and clear.
Viewfinder
1 AF frame (p.40) 11 Sensitivity (p.51)/
Exposure compensation
value
2 Spot metering frame
(p.52)
3 AF point (p.56) 12 AE Lock (p.49)
4 Flash indicator (p.53) 13 Change AF Point (p.56)
5 Focus Method (p.54) 14 Multi-exposure (p.63)
6 Shutter speed 15 AE Metering (p.52)
7 Aperture value 16 Shake Reduction (p.22)
8 Focus indicator (p.40) 17 Flash Exposure
Compensation (p.53)
9 EV bar scale/Electronic
Level (p.17) 18 EV Compensation
(p.48)/Bracketing (p.62)
10 ISO/ISO AUTO
19 File Format (p.44)
1
4
19
181716151413
61011
12
2
1
3
5 7 8 9
