3. Select Use the table microphone, and then click OK.
I M P O R T A N T
You are unable to change this setting later, so ensure you select the correct option.
The First things first dialog box and a dialog box prompting you to check the display settings
appear.
4. In the First things first dialog box, select Use recommended settings, and then click Accept.
5. In the dialog box prompting you to check the display settings, click OK.
Another dialog box appears, and Control Panel opens.
6. In Control Panel, configure the displays as follows:
I M P O R T A N T
o
Align the top of all displays as shown in the above diagram.
o
Set the console as the main display by clicking its thumbnail and then selecting
Makethismy main display.
o
Position the console to the right of the interactive flat panels as shown in the above
diagram.
o
You are unable to change these settings later, so ensure you configure the displays
correctly.
T I P
To determine which display is which, press Identify. Each display’s number appears briefly on
the display.
7. In Control Panel, click Apply and then click OK.
8. In the dialog box, click OK.
The Lync appliance restarts.
