2. Click Connection Wizard.
The SMART Connection wizard appears. The wizard detects your room system’s SMART
interactive products.
3. Select the first interactive flat panel in the list, and then click Next.
4. Select Product is being set up for the first time, and then click Next.
5. Click Calibrate.
The calibration screen appears on the console.
6. Move the calibration screen to the selected interactive flat panel by pressing the spacebar on the
keyboard or the Orient button on the interactive flat panel’s color select module.
N O T E
If you’re configuring a room system with two interactive flat panels, you need to determine
which interactive flat panel you selected in step 3. To do this, attempt to complete step 7 on
the interactive flat panel you moved the calibration screen to. If the calibration screen doesn’t
respond to touch on this interactive flat panel, move the calibration screen to the other
interactive flat panel and then repeat step 7.
