CHAPTER 3
PART REPLACEMENT AND RELATED ADJUSTMENT
This chapter presents printer disassembly and reassembly procedures. Please note the following important
points.
1. Always disconnect the power cord from the AC outlet before beginning work.
2. Except where otherwise indicated, the reassembly procedure is the reverse of the disassembly
procedure.
3. Coat screw heads with locking sealant after completing of reassembly.
4. Refer to Chapter 4 Section 2 for information about lubrication. (Chapter 3 does not include any
lubrication information.)
Note: This printer has no adjustment sites.
1. Upper Case Unit ..................................................................................................29
2. Auto-Cutter Unit ..................................................................................................29
3. Printer Mechanism ..............................................................................................30
4. Near-End-Sensor Unit .........................................................................................30
5. Power Unit............................................................................................................31
6. Main Logic Board ................................................................................................32
7. Fuses ....................................................................................................................32
8. Thermal-head Unit...............................................................................................33
