DECEMBER 31, 2003 11 AC500
DOOR COMPONENTS-SINGLE DOOR OPTION
Ref. Part
No. No. Description
AFTER JANUARY 01, 1997
t 33933 Door Assy, Solid (Qty 1)
1 t 33886 Door Assy, Glass (Qty 1)
2 31704 Glass Assy, Door (14" x 20") (Qty 1)
3 R6313 Handle
4 R2296 Catch & Latch Assy
20734 Microswitch Assy, Pictured on page 12
33907 Bracket, Door Switch
5 30761 Arm, Door Upper &/or Lower (Qty 2)
31919 Gasket Assy, Perimeter Door (4 Piece) (Qty 1)
Pictured on page 12
16470 Nameplate Assy., Blodgett 10" (Qty 1)
BEFORE JANUARY 01, 1997
6 t 30770 Door Assy, Sld (Qty 1)
t 31770 Door Assy, Gls (Qty 1)
2 31704 Glass Assy, Door (14" x 20") (Qty 1)
7 30680 Handle, Door (Qty 1)
8 17946 Catch Assy, Door (Qty 2)
NOTE: One is located on the top of the door and
the other is located on the bottom of the door
31206 Plate, Striker Door Latch (Qty 2)
31240 Microswitch Assy, Door Pictured on page 12
30940 Bracket, Door Switch (Qty 1)
9 35883 Arm, Door Upper (Qty 1)
10 35884 Arm, Door Lower (Qty 1)
90004 Bushings, Door Hinge (Set of 2)
31772 Cam Assy, Door Switch (Qty 1)
31919 Gasket Assy, Perimeter Door (4 Piece) (Qty 1)
Pictured on page 12
16470 Nameplate Assy., Blodgett 10" (Qty 1)
31747 Decal, Logo "The Achiever" (Qty 1)
FOR UNITS AFTER 01/01/97
3
OLD-BEFORE 01/01/97
NEW-AFTER 01/01/97
10
9
1
t Doors Are Not Returnable
8
5
5
2
t Doors Are Not Returnable
4
