Page 20
DUAL
BREWERS
PROGRAMMING THE BREWER (cont.)
SET NEW RECIPES (cont.)
SET NEW RECIPE:
If not using a Smart Funnel (with a computer chip)
and/or a G9-2T DBC or MHG Grinder, the brewer will
function as a standard Bunn Single/Dual Brewer:
It is possible to operate the brewer without using
a Smart Funnel and/or a G9-2T DBC or MHG Grinder.
If a standard funnel, or if a non-DBC grinder is used
the brewer will automatically select a NO NAME coffee
when the BREW switch is pressed. This means that
no name was read from the funnel's handle.
There is a NO NAME coffee program that can be
set in the SINGLE brewer and two NO NAME coffee
programs that can be set in the DUAL brewer which are
referred to as NO NAME LEFT and NO NAME RIGHT.
The left and right sides of the DUAL brewer can be set
up independently of each other. This includes BREW
VOLUMES, BYPASS PERCENTAGES, PULSE BREW
TIMES, and DRIP-OUT TIMES. The brewer will perform
in the same capacity as a standard Bunn Single/Dual
Brewer.
The instructions for programming the NO NAME
settings are on the following pages. The same steps
are followed for setting the recipe as those that are
used to MODIFY A RECIPE, beginning on page 21.
Note that on SINGLE brewers, when the display
reads NO NAME, that is when MODIFY should be
pressed in order to set the parameters for the NO
NAME coffee.
On DUAL brewers, when the display reads NO
NAME LEFT, that is when MODIFY should be pressed
in order to set the parameters for the NO NAME LEFT
coffee. Otherwise, press NEXT to display NO NAME
RIGHT. At this point, MODIFY should be pressed in
order to set the parameters for the NO NAME RIGHT
coffee.
NOTE: Before beginning setup, insert funnel(s) into
the funnel rails (both sides on DUAL brewers), and
place a GPR Server(s) beneath the funnel(s).
REVIEW RECIPES?
NO YES
NO-NAME
MODIFY SHOW NEXT
NO-NAME LEFT
MODIFY SHOW NEXT
NO-NAME RIGHT
MODIFY SHOW NEXT
BREW OZ. XX.X
(-) DONE (+)
(COFFEE NAME)
MODIFY SHOW NEXT
EXIT TO
NEXT FUNCTION
SCREEN
SINGLE
BREWERS
41343 080108
