11
Installation Checklist
WARNING
To ensure a safe and proper installation, the following
checklist should be completed by the installer to
ensure that no part of the installation has been
overlooked.
Proper installation is the responsibility of the
homeowner. The importance of proper installation of
your Dacor range hood cannot be overemphasized.
•
•
Is the blower assembly mounting bracket properly
attached to the wall according to the instructions on
page 6?
Is the blower assembly tightly secured to the mounting
bracket with the machine screws (see page 8)?
Is the duct work completely installed? Are all joints
attached with sheet metal screws and wrapped with
duct tape (see pages 5 and 7)?
Is the range hood wired and grounded according to
these instructions and in accordance with all applicable
electrical codes (see pages 5 and 9)?
Is the tempered glass hood attached to the blower
assembly as specified in this manual (see page 10)?
Are the filters properly installed according to the use
and care manual?
Has proper operation been verified?
Have any problems been noted on the warranty card
or during the on-line activation? Has the warranty been
activated on-line or the warranty card been filled out
completely and mailed?
□
□
□
□
□
□
□
□
INSTALLATION INSTRUCTIONS
Verify Proper Operation
Turn on power at the junction or fuse box.
If the control panel is not lit, turn on the main power
switch located next to the light fixture on the underside
of the hood.
Touch the light key. Verify that all the lights come on.
Touch the light key again to turn the lights off.
Touch the blower “+” key once and release. Verify that
one light is showing on the blower speed indicator and
that the blower is on at low speed.
Touch and release the blower “+” repeatedly, three
times. Verify that with each touch of the key the number
of lights on the blower speed indicator increases and
that the blower speed increases.
Touch and hold the blower “-” key until the blower
turns off.
If the hood fails to operate properly:
Verify that power is supplied to the hood.
Check the electrical connections to ensure that the
installation has been completed correctly.
Repeat the above test.
If the appliance still does not work, contact the Dacor
Customer Service Team at (800) 793-0093.
Do not attempt to repair the appliance yourself. Dacor
is not responsible for service required to correct a faulty
installation.
1.
2.
3.
4.
5.
6.
7.
•
•
•
•
