1
TABLE OF CONTENTS
What You Need to Know About
Safety Instructions
The Important Safety Instructions and warnings in
these instructions are not meant to cover all possible
problems and conditions that can occur. Use common
sense and caution when installing, maintaining or
operating this or any other appliance.
Always contact the Dacor Customer Service Team
about problems and conditions that you don’t
understand.
•
•
Safety Symbols and Labels
DANGER
Immediate hazards that WILL result in severe personal
injury or death.
WARNING
Hazards or unsafe practices that COULD result in
severe personal injury or death.
CAUTION
Hazards or unsafe practices that COULD result in minor
personal injury or property damage.
IMPORTANT SAFETY INSTRUCTIONS
BEFORE YOU BEGIN...
DANGER
To avoid the possibility of explosion or fire, do not store or use combustible, flammable or explosive vapors and liquids
(such as gasoline) inside or in the vicinity of this or any other appliance. Also keep items that could explode, such as
aerosol cans away from cooktop burners, ovens and range hoods. Do not store flammable or explosive materials in
adjacent cabinets or areas.
Save these instructions for the building inspector’s use and for future reference by the owner.
Important:
Installer: In the interest of safety and to minimize
problems, read these installation instructions
completely and carefully before you begin the
installation process. Leave these installation
instructions with the customer.
Customer: Keep these installation instructions for
future reference and the local electrical inspector’s use.
•
•
If you have questions or problems with installation,
contact your Dacor
dealer or the Dacor Customer
Service Team.
Dacor Customer Service
Phone: (800) 793-0093.
Email: customerservice@Dacor.com
W
eb site: www.Dacor.com
•
Before You Begin...
..................................................1
Important Safety Instructions .................................1-3
What You Need to Know About Safety Instructions ......... 1
General Safety Precautions ............................................. 2
Product Specifications
.............................................3
General Specifications ..................................................... 3
Dimensions ...................................................................... 3
Preparing for Installation
.......................................4-5
Verify the Package Contents ............................................ 4
Location Planning ............................................................. 4
Electrical Power Supply ................................................... 5
Plan the Duct Work Installation ........................................ 5
Installation Instructions
....................................... 6-11
Install the Electrical Connection ....................................... 6
Install the Chimney Mounting Bracket ............................. 6
Install Blower Mounting Bracket ....................................... 6
Install the Duct Work ........................................................ 7
Hanging the Blower Assembly ......................................... 8
Electrical Connection ....................................................... 9
Install the Chimney .......................................................... 9
Install the Hood ................................................................. 10
Verify Proper Operation ..................................................11
Installation Checklist .......................................................11
Notes
...............................................................12-13
