6
Dimensions and clearances
The cooker must be installed no less than 50 mm away from any side walls which exceed the
height of the cooktop.
The cabinetry surrounding the cooker must be made of heat-resistant material and must be able
to withstand temperatures of 65 °C above room temperature.
Do not install the cooker near flammable materials (eg curtains).
If you stand the cooker on a pedestal, make sure you provide safety measures to keep it in place.
Installing the cooker above a plinth without fitting the adjustable feet
In that case the cooker stands directly above the plinth; make sue you provide safety measures
to keep it in place. Revise the installation dimensions accordingly considering that the feet have
the following measures: min 155 mm - max 180 mm.
50 mm
650 mm
500 mm
450 mm
Installation instructionsInstallation instructions
Cooker overall dimensions [mm]
•
height:
min 892 - max 917
•
product width: 898
•
depth: 600
•
cavity width 900
Fig. 1 Dimensions and
distances from cooker
