Transformer
supply transformer
for logic board
contactor ignition
and fan
2
1
3
4
7
6
5
8
23VAC outlet (logic supply)
mains supply voltage
( 208V/ 230V / 400V AC)
230VAC outlet (contactor ignition)
230VAC outlet (fan)
Recti er And Transistor Module
-
+
2 1
3
+
-
C2/E1
E2
C1
C2/E1
C1
E2
solder side view
power board
Item 2: transistormodul IGBTItem . 1: rectier
solder side view
L3
L1
L2
rectier board
