movable Oven Bottom
The oven bottom
can
be removed
to
make
cleaning easier.
To
remove:
1.
Grasp
the
oven bottom at
finger
slots on
each
side.
RWO-Y
2.
Lift
front
edge
of
the oven bottom
enough
to raise
th~
tabs
from
s1[)[s in the
front
frame.
3.
Push the oven bottom back
tibout
1
/4”
to
release the
tltinge
from
the
front
frame, then pull out.
To replace the oven bottom:
1.
Slide the oven bottom into the oven so rear tabs
fit
into slots in the rear wall of the oven.
2. Grasp the oven bottom at
finger
slots
and
push it
back
and
then down
to
hook the
flange
under the
front
frame.
3. Fit the front tabs into
slots
in
front
frame.
Finger
slot
The oven bottom has a porcelain enamel finish.
To make cleaning easier, protect the oven bottom
from
excessive
spillovers.
This is particularly
important when baking
a
fruit pie or other
foods
with
‘~
tic id content. Hot fruit fillings or foods that are
.ic
in content such as milk, tomato or sauerkraut
and
sauces with vinegar or lemon juice, may cause
pitting and damage to the porcelain enamel surface,
To protect the oven bottom surface,
place a
piece
of aluminum
foil
slightly larger than the baking
dish on the shelf below to catch any
boilovers.
It
should not completely cover the shelf as this would
cause uneven heat in the oven. Aluminum foil should
not be
placed
on the oven bottom.
If a
spillover
does occur on the oven bottom,
allow the oven to
cool
first.
Remove the oven bottom
for
easier cleanup and to prevent damage to the
continuous cleaning oven coating.
Frequent
wipings
with mild soap and water
(particularly after cooking meat) will prolong the
time between major cleanings. Rinse thoroughly. Soap
left
on
the
oven bottom can cause stains.
For heavy soil,
use a mild abrasive cleaner and
follow
label instructions, using a thin layer of cleaner.
Use of rubber gloves is recommended. Wipe or rub
lightly on stubborn spots. A commercial oven cleaner
may also be used, following package directions.
Painted Surfaces
Painted surfaces include the control panel and drawer
front. Clean these with soap and water or a vinegar
and water solution. Do not use commercial oven
cleaners, cleansing powders, steel wool or harsh
abrasives on any painted surface.
((c]ntitzL4ed
fIe.xt
page)
23
