Oven Features
E) Oven Temperature Control - With infinite bake temperature and broil control. All units feature "auto gas shutoff",
which means that if for any reason the flame goes out, gas to the oven burner shuts off!
F) Gas Oven Features: -baking
-3 position racking
-2 cubic feet of energy efficient area (.05 cubic meters)
-13,500 BTU (3.96Kw) oven burner
Other Features (see fig. 8)
G) Digital Clock - With minute minder.
H) Broiler - Broiler drawer located under the oven, glides open for easy access, for all your broiling needs.
I) More Storage - (model 7100 only) lift and open the cast door to gain access to more storage area.
J) Cabinet Door - the minute minder, exhaust fan control and overhead light switch are concealed behind the cabinet
door.
K) Three position switch - Controls high and low for exhaust fan centre position is “OFF”.
L) On -off switch - controls overhead light in exhaust hood.
L
K
G
Fig. 8
