Model 7100 / 9100 Gas Range Parts Chart
7551 Control Valve Medium Burner
7552 Control Valve Large Burner
7555 6 burner reignition harness c/w switches
7556 4 burner reignition harness c/w switches
7557 Medium Burner Cap
7558 Large Burner Cap
7559 Medium Flame Spreader
7560 Large Flame Spreader
7561 Medium Burner Base
7562 Large Burner Base
7569 Ignition Electrode (1200MM Lead)
7570 Ignition Electrode (900MM Lead)
7571 Ignition Electrode (600MM Lead)
7577/7376 Oven Burner Control (serial number required)
7580 7100 Manifold Weldment
7581 9100 Manifold Weldment
7590(7304) Spark Module (0+6)
7591(7404) Spark Module 0+2 (7100 only)
7917 Broiler Drawer Assembly
8200 Light Socket & Housing
8202 Oven Light Ass’y
8204 Oven Lens
8313 Curved Band - Cook Surface (9100 only)
8449 Oven Rack Support
8452 Oven Rack
8455 Base Rail Front / Side
8456 Base Rail Rear (9100 only, not shown)
8536 Closet Wrap (9100 only)
9106 Utility Drawer Frame
9141 Oven Door Frame Weldment
9147 Gas Oven Door Gasket
9237 Electronic Minute Minder
9530 Stove Top (9100 only)
9533 Valve Cover Plate (9100 only)
15211 Splash Back (7100 only)(serial number req’d)
15451 Cresting Panel (7100 only)(serial number req’d)
16071 Front Cabinet Door Panel (7100 only) - (serial
number req’d)
16601 Reservoir Front Insert Panel (7100 only) -(serial
number req’d)
45231 Splash Back (9100 only)(serial number req’d)
45451 Cresting Panel (9100 only) (serial number req’d)
46071 Front Cabinet Door Panel (9100 only) - (serial
number req’d)
91051 Drawer - Front Panel(serial number req’d)
13021 Fire Door Panel (7100 only) (serial number
req’d)
H-306 Ash Door Hinge - Pins (7100 only)
H-976 Spark Ignitor “O” ring
Please order by part number. Parts may be ordered from
your dealer or direct from Heartland Appliances Inc. Phone
factory for prices and ordering instruction. Phone 519-650-
5501 ask for the order desk.
1110 Oven Door Handle Stanchion
1120 Outer Oven Door Panel
1125 Oven Door Thermometer (Non Functional)
1307 Fire Door Frame (7100 only)
1311 Ash Pan Door - Complete (7100 only)
1320 Wire Spring Handle (7100 only)
1325 Bell Damper Handle w/rod (7100 only)
1327 Cast Bell Damper Handle (7100 only)
1330 Bell Damper (7100 only)
1546 Heartland nameplate/Clips
1551 Right Cabinet Bracket
1556 Left Cabinet Bracket
1570 Lower Cabinet Strip (7100 only)
1575 Upper Cabinet Strip (7100 only)
1588 Right Cabinet Cast Corner
1592 Left Cabinet Cast Corner
1596 Right Cresting Corner
1599 Left Cresting Corner
1610 Cabinet Door Handle
2455 Base Rail Front (7100 only)
2456 Base Rail Rear (7100 only, not shown)
3556 Gas Regulator
4012 Base Leg
4570 Lower Cabinet Strip (9100only)
4575 Upper Cabinet Strip (9100 only)
5208 Reservoir Front (7100 only)
6029 Ash Catch (7100 only)
6197 2 Speed Blower Control Switch
6198 Range Light Switch
6202 Oven Light Bulb - 40W
6313 Curved Band - Cook Surface (7100 only)
6397 Oven Door Handle
6437 Oven Door Hinges L&R (not shown)
6455 Broiler Pan & Cover 2 Pc
6522 Exhaust Hood Deflector
6536 Closet Wrap (7100 only)
6675 Exhaust Filter (9100 only)
6676 Exhaust Filter (7100 only)
6677 Exhaust Adapter Boot to 3 1/4 x 10
6679 Exhaust Blower
7073 Broiler Drawer Rack
7123 Broiler Drawer Spring
7161 Oven Control Knob
7162 Top Burner Control Knob
7355 Oven Burner
7364 Oven Burner Igniter/Wire
7374 Flue Deflector
7518 Gas Oven Drawer Heat Shield
7521 Oven Bottom Pan
7528 Valve Cover Plate (7100 only)
7530 Stove Top (7100 only)
7545 Grate - Cast
TO ENSURE THE CORRECT COLOR MATCH WHEN ORDERING
COLORED PANELS, BOTH THE COLOR AND SERIAL NUMBER
MUST BE PROVIDED.
