14
Rough in
Measurements
52”
(133 cm)
with bottom drawer fully open
43-3/4”
(111 cm)
with oven
door open
0” clearance
to the back
3” (7.6 cm)
14”
(36 cm)
29-1/2”
(75 cm)
3-7/8”
(10 cm)
Cresting
Panel
37-3/4”
(96 cm)
11-3/8”
(29 cm)
62-3/8”
(159 cm)
36-1/8”
(92 cm)
28”
(72 cm)
39-3/4”
(101 cm)
56”
(142 cm)
36-1/8”
(92 cm)
4-3/4”
(12 cm)
30”
(76 cm)
Range Hood
Outlet
3-1/4” x 10”
(8cm x 25cm)
20”
(51 cm)
47-1/2”
(121 cm)
39-3/4”
(101 cm)
66-1/4”
(169 cm)
Exhaust Hood
(female)
Receptacle
Power
Cord
Gas Inlet 1/2” NPT
Dimensions
Model 7200
(6” clearance to any com-
bustible side wall)
Range Hood Outlet
3-1/2” x 10-1/2”
(8.9 cm x 26.7 cm)
6” (16 cm)
24” (61 cm)
Counter
Depth
56”
(142 cm)
13” (33 cm)
cabinet depth
21”
(54cm)
min 18”
(46 cm)
min 36”
(91.4 cm)
5-3/8”
(14 cm)
30”
(76 cm)
Location
of Stove
Gas
Outlet
481/2” (123 cm)
1” stove clearance must be
measured from the left side
Figure 11
Figure 12
481/2” (123 cm)
