16
Features
Cooking Controls
The cooking controls are located on the right hand side of the cooktop; these controls offer an infinite number of heat
settings for ease and accuracy in cooking and baking.
Sealed Burner Features (see fig. 13)
A) Centre Burners - are two maximum 8,000 BTU (2.34 kW)(L/P 7,000 BTU) with simmer of 600 BTU (.2 kW) sealed
gas burners, easy clean, for medium duty cooking tasks.
B) Right Burners (48" models only) - front sealed burner is maximum 10,000 BTU (2.93 kW)(L/P 9,000 BTU) with sim
mer of 1000 BTU (.3 kW) and rear is maximum 8,000 BTU (2.34 kW)(L/P 7,000 BTU) with simmer of 600 BTU (.2
kW), one for large jobs, one for small, easy clean.
C) Left Burners - front sealed burner is maximum 10,000 BTU (2.93 kW)(L/P 9,000 BTU) with simmer of 1000 BTU
(.3kW) and rear is maximum 8,000 BTU (2.34 kW)(L/P 7,000 BTU) with simmer of 600 BTU (.2 kW) to accurately
maintain temperature.
D) Gas Burner Controls - allow an infinite selection of cooking temperatures, 4 controls on model 9200 and 6 controls
on model 7200. All models feature "auto-reignition", which means if for any reason the flame goes out, it
automatically begins to spark to re-ignite the burner!
A
B
C
D
F
G
I
E
H
Figure 13
