Hobart HGC5X Convection Oven User Manual



– 14 –
PROGRAMMABLE CONTROLS (Models HGC5D AND HGC5DX)
Always displays [HR:Min] when setting the time.
Displays [HR:Min] if the countdown time is more than 1 hour.
Displays [Min:Sec] if the countdown time is less than 1 hour.
Displays temperature in °F.
C & H
MODE
Indicates the oven is in the Cook & Hold Mode.
OVEN
READ
Y
Indicates the oven is preheated and ready for cooking.
OVEN
HEATING
Indicates the oven is preheating or burners have cycled on to
maintain temperature setting.
PRIMARY
Primary indicates menu items 1, 3 or 5.
SECONDAR
Y
Secondary indicates menu items 2, 4 or 6.
Up arrow increases and Down arrow decreases a displayed
time or temperature value (if arrow keys are lit).
TEMPERATURE: Use with SET to set the oven temperature.
SET
SET: Use with time or temperature.
TIME: Use with SET to manually set the cooking time.
COOK
&
HOLD
Selects Cook & Hold mode; also selects low fan speed.
START
STOP
Press once to start; press a second time to stop.
1/2
3/4
5/6
Select Menu Cook Times. Press once for primary (1, 3 or 5).
Press a second time for secondary (2, 4 or 6). See next page.
1
2
3
4
5
Rack Buttons select individual Menu/Rack Number Cook
Times — once programmed.
1
2
SET
PRIMARY
SECONDARY
MENU SELECT
6
5
POWER LIGHTS
START
COOK
&
HOLD
STOP
NO IGNITION
ON
OFF
ON
DOWN
COOL
OFF
MENU RACK
3
4
5
4
3
2
1
PL-53540
MODE
C & H
READY
OVEN
HEATING
OVEN
