H. Startup
WARNING
1. All parts are factory-adjusted. Improper adjustments may adversely affect
safety, performance, component life, and warranty coverage.
2. If the icemaker is turned off, wait for at least 3 minutes before restarting the
icemaker to prevent damage to the compressor.
3. At startup, conrm that all internal and external connections are free of leaks.
1) Open the water supply line shut-off valve.
2)Makesurethepowerswitchisinthe"OFF"position.Plugtheunitintotheelectrical
outlet. If you have to slide the unit back for a built-in installation, make sure you do not
damage or pinch the water supply, drain connections, or power cord.
3) If required by sanitation code in your area, seal the perimeter where the machine
touches the oor with approved caulk compound in a smooth and easily cleanable
manner.
4)Movethepowerswitchtothe"ON"positiontostarttheautomaticicemakingprocess.
5) Once the unit starts to produce ice, allow it to run for another 30 minutes.
6)Movethepowerswitchtothe"OFF"position.
7) Remove the ice produced, then clean the storage bin liner, door liner, and door gasket
using a neutral cleaner. Rinse thoroughly after cleaning.
8)Movethepowerswitchtothe"ON"positiontostarttheautomaticicemakingprocess.
9) To conrm bin control operation, hold ice in contact with the bin control thermostat bulb.
The icemaker should stop within 10 seconds.
I. Notes About Usage
•Washyourhandsbeforeremovingice.Usetheplasticscoopprovided.
•Thestoragebinisforiceuseonly.Donotstoreanythingelseinthestoragebin.
•Ificeisnotusedonaregularbasis,itmaybondtogetherinthestoragebin.Inthis
case, discard the bonded ice and allow the icemaker to make fresh ice.
