Hoshizaki KM-151BAH Ice Maker User Manual



15
7) Same as step 4.
8) Move the Control Switch to the “ICE” position to fill the Water Tank with water.
9) After 3 minutes, move the Control Switch to the “WASH” position.
10) After 5 minutes, move the Control Switch to the “OFF” position.
11) Same as step 4.
12) Repeat steps 8 through 11 three more times to rinse thoroughly.
13) Disconnect the Silicone Hose and Overflow Pipe. Next, remove the Water Tank by
pressing down on the snaps on the Bracket (L) (R) and pulling the tank towards you
slightly and pushing it down. Be careful to avoid breakage when handling the parts.
See Fig. 7.
Fig. 7
Bracket (L)
Snap
(both ends)
14) Pull the Cube Guides (quantity varies depending on model) upward to remove them
from the Water Tank. They are snapped in place. See Fig. 8.
15) Same as step 1.
Evaporator
Pump Motor
Bracket (R)
Float Switch
Cube Guide Water Tank
* This illustration shows KM-61BAH. The Float Switch location
is different for KM-151BAH/BWH (behind the Pump Motor).
Push
