SAFETY PRECAUTIONS
Always disconnect power to the dispenser before servicing or cleaning.
Never place hands inside of hopper or gate area without disconnecting power to the dispenser. Agitator rota-
tion occurs automatically when the dispenser is energized!
This ice dispenser has been specifically designed to provide protection against personal injury and eliminates
contamination of ice. To insure continued protection and sanitation, observe the following
ALWAYS be sure the removable lid is properly installed to prevent unautho-
rized access to the hopper interior and possible contamination of ice.
ALWAYS be sure the upper and lower front panels are securely fastened.
ALWAYS keep area around the dispenser clean of ice cubes.
CAUTION: Dispenser cannot be used with crushed or flaked ice.
Use of bagged ice which has frozen into large chunks can void warranty. The dispenser
agitator is not designed to be an ice crusher. Use of large chunks of ice which “jam up”
inside the hopper will cause failure of the agitator motor and damage to the hopper. If bagged ice
is used, it must be carefully and completely broken into small, cube-sized pieces before filling into
the dispenser hopper.
GENERAL DESCRIPTION
The D3030 ice dispensers solve ice service needs in the sanitary, space saving, economical way. Designed to
be manually filled with ice from any remote ice making source, these dispensers will dispense cubes (up to
1-1/4” in size), cubelets and hard-chipped or cracked ice.
Table 1. Specifications
Model: D3030
Ice Storage: 220 lbs.
Electrical: 120/1/60 5.5 Amp
Drain Connection: 3/4” FPT
Electrical Connection: 6’, 3-Wire Cord with 3-Prong Ground Type Plug
Dimensions: 30”W x 30” D x 36”H
