INSTALLATION (CONT.)
Chemical Connections
NOTE:
Consult a qualified chemical supplier for your chemical needs.
1. A chemical signal terminal block is supplied for chemical dispensing equipment.
2. The terminal block is located below the control panel fuse block.
3. The detergent signal is limited to a maximum load of 1 Amp. Signal voltage is 115VAC.
4. The Rinse aid signal is limited to a maximum load of 1 Amp. Signal voltage is 115VAC.
5. The feeder units must have separate neutrals for detergent and rinse aid connections.
6. A 1/2” detergent injection point is provided at the rear and left side of the dishwasher.
7. Detergent may be added manually, put in three tablespoons of powdered domestic deter-
gent into the wash tank after the machine has been filled, then add another tablespoon full
after every fourth or fifth cycle. This is not recommended except in a temporary situation,
ex: dispensing equipment is down, out of chemical and awaiting supplier, etc.
8. Rinse aid injectors can be purchased separately. There is a 1/4” NPT rinse aid injection
point provided in the final rinse manifold. Use a liquid rinse aid. Contact your local
chemical supplier about product type for factors such as water hardness etc.
Peristaltic Detergent Pump
To prime the peristaltic pump:
1. Insert pump inlet hose into the detergent container.
2. Close machine door and switch machine on.
3. Allow wash tank to fill up then press detergent pump prime switch to prime inlet and
outlet hose.
4. Stop priming when detergent reaches machine.
Machine will not fill unless READY light is on and door is shut. Turn power off before
opening door as machine will cycle again when door is closed. Pump operates during the wash
cycle and is set to run for approximately 10 seconds. Use yellow adjusting tool, supplied with
the instructions, to adjust cam 6 to vary this time. Increase cam gap (away from 0 mark) to
increase pumping time.
