REPLACEMENT PARTS
13
WASH TANK ASSEMBLY
Fig.3 Part
Item No. No. Part Description Qty.
1 32590001 Hose Outlet .............................................................................................. 1
2 ASS24 Hose Clamp ............................................................................................. 2
3 40030000 Spindle..................................................................................................... 2
4 6037 Backnut 126*40mm ................................................................................ 1
5 1896 Drain Waste Gasket ................................................................................. 1
6 3904 Wash Pump Assy .................................................................................... 1
7 C160603 Pump Inlet Flange ................................................................................... 1
8 24.38210 Hose Inlet ................................................................................................ 1
9 C16301 Drain Outlet ............................................................................................. 1
10 C180704 Overflow Pipe ......................................................................................... 1
11 1238 Wash Inlet Filter ...................................................................................... 1
12 ARP229 Oring........................................................................................................ 1
13 ARP241 Oring........................................................................................................ 1
14 8835 Set Screw 5/6” x 1/2” .............................................................................. 2
15 8568 Washer Spring 5/16” ............................................................................... 2
16 8058 Nut 5/16” ................................................................................................. 2
17 8106 Nut Hex M6............................................................................................. 4
18 88461 Bolt Hex Head M6 x 12 .......................................................................... 2
19 8800 Screw Pan Head M4 x 6 .......................................................................... 2
20 30201 Thermostat............................................................................................... 1
21 3032 Gland Nut ................................................................................................ 1
22 3033 Gasket Gland ........................................................................................... 1
23 3031 Gland Bulkhead ....................................................................................... 1
24 30071 Element Wash 1.8KW ............................................................................. 1
25 60030092 Door Switch Assy.................................................................................... 1
26 88021 Screw Pan Head M4 x 30 ........................................................................ 2
27 1557 Rack Guide .............................................................................................. 1
28 1560 Rack Guide Bracket ................................................................................ 1
29 60080017 Bolt Truss Head M5 x 12 ........................................................................ 2
30 60080015 Bolt Hex M6 x 16 .................................................................................... 4
31 8566 Washer Spring 1/4” ................................................................................. 8
32 8108 Nut Dome M6.......................................................................................... 4
33 ASS36 Hose Clamp ............................................................................................. 2
34 32510012 Wash Manifold ........................................................................................ 1
35 111151 C-Clip Float Switch (per float ball)......................................................... 2
36 110854 Dual Float Switch .................................................................................... 1
37 110750 Gasket float switch .................................................................................. 1
38 107589 Washer, lock 1/2” .................................................................................... 1
39 104584 Nut, Plain (1-2-13) .................................................................................. 1
