1.3.4 Ventilation and Fire Fighting System
1.3.4.1 Fire Fighting System - It is very important to install an adequate fire fighting system. The
sensing device that activates the fire fighting system should be located according to manufactures
recommendations to reduce false alarms.
1.3.4.2 Ventilation - The Pasta cooker must have proper ventilation to function safely and
properly. The ventilation system should be designed to allow for easy cleaning. Frequent cleaning
of the ventilation system and the cooker will reduce the chances of fire. Table 1-2 provides a list of
reference documents that provide guidance on ventilation and fire safety systems. This table may
not be complete and other nationally recognized standards may apply.
Table 1-1. Electrical Requirements For Pasta Perfect Cooker Models
Model Voltage and
Number Phase Arrangement Line Current
PE14 with 220 VAC 23.0 Amps
Basket Lift Single Phase (2 wires and a ground)
PE14 with 240 VAC 25.0 Amps
Basket Lift Single Phase (2 wires and a ground)
PE14 without 200 VAC 27.8 Amps
Basket Lift Single Phase (2 wires and a ground)
PE14 without 208 VAC 28.9 Amps
Basket Lift Single Phase (2 wires and a ground)
PE14 without 220 VAC 23.0 Amps
Basket Lift Single Phase (2 wires and a ground)
PE14 without 240 VAC 25.0 Amps
Basket Lift Single Phase (2 wires and a ground)
