RECOMMENDATIONS BREWING
9493
ENT a new value can be saved. On the
contrary, by pressing ESC the new value entering
is stopped and, as a result, the former counter
setting shall be considered.
When the set limit has been reached, the coffee
dispensing stops and the following two messages
are displayed:
"COFFEE DISPENS. "
"BLOCKED "
"SELECT PRODUCT "
"READY FOR USE "
Reset the counters by pressing the cappuccino
selection key
.
Washing cycle
This appliance is equipped with a rinsing cycle
program for the usual, daily and weekly rinsing.
If regularly used, this program effectively elimi-
nates the greasiness of coffee in inaccessible
parts and avoids alterations in the taste of
coffee.
Depending on the way the appliance is used, it
is advisable to rinse it every month or after max.
250 cups of coffee. The rinsing cycle lasts about
5 minutes, and it is divided into 4 cycles,
including the rinsing with cold water. Each cycle
is followed by a short pause of about 40
seconds.
Never stop the rinsing cycle.
Important: before starting the rinsing cycle,
always fill completely the water tank and put a
capacious container (min. 1 litre) under the
coffee dispensing unit, which is height-adjust-
able and can be removed for cleaning.
The rinsing cycle needs about 1 litre of water
(including final rinsing). From time to time, empty
the water tank.
By using the keys
move the asterisk to the
menu item WASHING CYCLE. To enable this
menu item use the ENT key.
The following message appears on the display:
"WASCHING CYCLE "
This function starts the rinsing cycle with water of
those parts concerned with the coffee dispens-
ing. When the rinsing cycle ends, the following
message appears on the display:
"SELECT PRODUCT "
"READY FOR USE "
Dosage of ground coffee
33
The coffee dosage adjustment lever (18) allows the
selection of the grinding coffee amount from 6 to 9
grams. Place lever (18) on the required position.
RECOMMENDATIONS
Prolonged idleness
If the machine hasn’t been used for a prolonged
period, it is advisable for hygienic reasons to run
a rinse cycle through the machine.
Place a cup under the steam/hot water spout (7)
and fill it with water by operating the hot water
knob.
Preheating cups
Cups may be preheated by placing them on the
special cup heating plate.
Temperature led
When starting the machine, the following
message is displayed:
"WARMING UP...... "
As soon as the operating temperature has been
reached, the following message is displayed:
"SELECT PRODUCT "
"READY FOR USE "
Empty coffee bean container
When coffee beans run out, the coffee grinder
stops and the following message is displayed:
"COF. BEANS EMPTY "
Fill the container and restart the cycle.
Empty water tank
When water runs out, the program stops
automatically and the following message is
displayed:
"WATERTANK EMPTY "
Fill the tank and restart the cycle.
Grounds container warning light
As soon as there are 30 grounds in the container,
the following message is displayed:
"DREGDRAWER FULL "
"READY FOR USE "
The machine does not stop: remove the grounds
container and empty it.
Grind adjustment
If the coffee flows too quickly (coarse grind) or too
slowly (fine grind) into the cup, adjust coffee grinder.
The recommended grind level is position 5.
Should grinding be too coarse, adjust it on a
lower value (e.g. from 5 to 3). On the contrary,
should grinding be too fine, adjust it on a higher
value (e.g. from 5 to 7).
Adjust the grind level only when the coffee
grinder is running. Avoid any extreme adjustment
(for instance on position 1) whenever possible.
It is preferable to try another coffee blend, since
not all coffee blends are suitable.
Coffee blends
Make sure coffee is fresh. An espresso roast is
preferable.
In order to obtain a strong and aromatic espres-
so coffee, use special blends suitable for espres-
so coffee machines and special cups with thick
sides.
Keep coffee in a cool place, in an hermetically
sealed container.
Operation time
The machine may be kept on all day long.
However, in case of a prolonged period of
idleness, it is advisable to enable the energy
saving function by pressing the standby
switch. If the timer is properly programmed, this
operation is automatic: for this purpose, see
page 88.
In case of a prolonged period of idleness, it is
advised to switch the main switch (4) off; once
switched on again, the machine will be ready
to be used within two minutes.
Switching off the machine
Switch the machine off only after the coffee cycle
has been concluded.
BREWING
Cup level filling
This machine allows the precise dosage of the
courtesy of
