DESCRIPTION OF SYMBOLS
TECHNICAL DATA
80 81
How to use the instructions
These instructions cannot anticipate every possible
use of the machine.
For further information or questions concerning
specific situations or problems, please contact
the local dealer or manufacturer directly.
The warning triangle shows all important safety
indications to ensure the user’s safety.
The non-observance of said instructions may
cause serious injuries!
The first cover page of the manual shows figures
relevant to the text. Thus, keep it open while
reading the instructions.
B
Reference to figures, parts of the machine and
control elements are given by numbers or letters,
as figure B exemplifies.
Save these instructions carefully and
make sure to hand them to other
users.
Table of contents
Page
81 Technical data
83 Safety rules
85 Machine controls and parts
85 Description of the control panel
86 Unpacking/Installation
86 Power supply connection
86 Starting and use
87 Drainage
Page
87 Programming the machine
93 Recommendation
94 Grind adjustment
94 Brewing
96 Incorporated Safety Devices
97 Cleaning and maintenance operations
99 Descaling
103 Troubleshooting
Voltage rating see rating plate on the back of the machine
Nominal power see rating plate on the back of the machine
Dimensions (length x width x height) approx. 465 x 380 x 395 mm
Machine case metal and plastic material
Weight approx. 16 kg
Cable length approx. 1.2 m
System free flow thermal cut-out, alternating piston pump
Temperature control electronic
Coffee grinder adjustment grinding adjustment device
Coffee grounds ejection automatic
Ground coffee dosage coffee releasing device
Cup programming 0-250 ml approx.
Water tank removable, transparent tank
Water regulation electronic, continuous
Capacity - water tank approx. 2.4 litres
- bean coffee container 300g bean coffee
Steam/hot water dispensing tube adjustable, supplied with burn protection
Steam/hot water dispensing adjustable, continuous
Heating time approx. 2 min.
Brewing time - espresso coffee approx. 20s/cup
- coffee approx. 30s/cup
- hot water approx. 60s/cup
- milk (cappuccino) approx. 60-90s cream/cup
Overheating protection incorporated
Insulation protection range I
Approvals see rating plate on the back of the machine
In compliance with EN regulation
EN 60335-2-15(96) - EN 60335-2-14(96) - EN 55014
Warranty
in compliance with the warranty certificate enclosed herein
Accessories (included in the machine price)
Measuring spoon
Central unit key
Cleaning brush
Water hardness detecting strips
The manufacturer reserves the right to make improvements to the appliance due to technological
advancement.
SAVE THESE INSTRUCTIONS
The lightning flash with arrowhead symbol, within
an equilateral triangle, is intended to alert the user
to the presence of unisulated «dangerous voltage»
within the product‘s enclosure that may be of
sufficient magnitude to constitute a risk of fire or
electric shock to persons.
The exclamation point within an equilateral triangle
is intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the
appliance.
