DRAINAGE / PROGRAMMING THE MACHINE
88
PROGRAMMING THE MACHINE
87
Remove water tank (11) from the machine,
remove its cover (12) and fill it with cold water
(approx. 2.4l). A valve on the tank bottom
prevents water from escaping.
Before installing the water tank in the
machine, make sure the coffee bean
container cover is properly fitted.
31
Install the water tank, slightly pressing over it to
fit the valve which will open automatically.
Do not fill the tank with an excessive quantity of
water.
Always fill the tank with fresh water only: hot
water as well as other fluids might damage the
tank. Never use carbon dioxide added water.
Do not switch on the machine on if the water tank
is empty: always make sure there is enough
water in the tank!
Connect the plug to the socket and press the main
switch. The following message will be displayed:
"WARNING UP...... "
Should
"ENERGY "
"SAVING "
be displayed, press button “Standby” to
disactivate the energy saving mode.
messages :
LANGUAGE PROGR. H. WATER
RINSING PROG. CAPPUC.
WATER HARDN. TOTAL COFFEE
CUP HEATER DESCALING
TEMP. L. COFFEE SIGN. DESCAL.
TEMP. COFFEE TIMER
TEMP. S. COFFEE VENDING
PREBREWING RINSING CYCLE
PREGRINDING
In order to exit from the program mode, press the
ESC key (
). The machine is in normal mode
again
Selecting single menus
Select the different menu items by means of the
keys
. The key ENT allows you to activate the
selected item. It is possible to modify the selected
figures in a menu item using the keys
. The key
ENT memorizes the selected options (for instance
“ON” for the cup heating plate).
Should you accidentally change some data,
press ESC (
) to leave the menu item without
saving the new options which were selected
accidentally.
Language selection
Move the asterisk to the menu item
“LANGUAGE” using the keys
. Press
ENT to activate this item. The following message
will be displayed:
"LANGUAGE "
"ENGLISH "
The keys allow you to change the set options :
“DEUTSCH”, “ITALIANO”, “FRANÇAIS”,
“ENGLISH”, “ESPAÑOL” or “PORTUGUES”.
Rinsing cycle function
If the rinsing cycle function is activated, the
machine that is started after a period of inactivity
starts a water rinsing cycle to the coffee dispensing
units automatically.
Move the asterisk to the menu item RINSING
CYCLE using the keys
and press ENT to
activate it.
The display shows:
"RINSING "
"ON "
You can modify the chosen item with the key
: on, off.
Water hardness adjustment
In order to adjust the water hardness, it is necessary
to test the water using the strip supplied with the
machine. Dip the strip into the water for a second,
shake off excess water gently, wait approx. 1
minute and read the results.
Move the asterisk at the end of the line to the
menu item “WATER HARDN.” using the keys
and select it by means of the ENT
button.
The following message will be displayed:
"WATER HARDN. "
"HARDNESS 3 "
The keys
allow you to change the set
options:
Drainage
Direct the steam/hot water spout on the drip tray
(2). Place a cup or another suitable container
under the dispensing tube, then turn the steam/
hot water knob counterclockwise. The pump
starts automatically. Wait until a regular water jet
is obtained, then close the knob. The machine is
now drained and ready to work.
The following message will be displayed:
"SELECT PRODUCT "
"READY FOR USE "
Important: It is advisable to drain the
machine before the first start, after a
prolonged period the machine has not
been used or whenever the water
tank has been completely emptied.
Furthermore, should the pump be defective, the
display shows:
"VENTILATE "
Programming the machine
32
To enter the programming mode, press the key
ENT (
pre-ground coffee) when the machine
is on and keep it pressed until the first two lines
of the programming mode are displayed:
"LANGUAGE "
"RINSING "
At the end of the line a blinking asterisk is
displayed, which can be moved up and down
with the keys
(tall and regular coffee).
If the asterisk is on the first menu, press
button
to move it on the second menu and vice versa.
The display shows the following sequence of
Sehr weiches Wasser
Weiches Wasser
Mittleres Wasser
Hartes Wasser
Hardness 4
Hardness 3
Hardness 2
Hardness 1
HARDNESS 1
(very soft water)
HARDNESS 2
(soft water)
HARDNESS 3
(medium water)
HARDNESS 4
(hard water)
