16
Model C712Important: To the Operator
050722
Once the syst em has initialized, the SAFETY
TIMEOUT screen will display and the alarm will be
on. (See Figure 9.)
SAFETY TIMEOUT
ANY KEY ABORTS
Figure 9
The SAFETY TIMEOUT screen will be displayed
with the alarm on, for 60 seconds or until any control
symbol is selected.
After the safety timeout has been completed and the
power switch is OFF, the following screen is
displayed. (See Figure 10.)
POWER SWITCH O FF
-=-=-=-=-=-
UNIT CLEANED
Figure 10
Power Switch ON
When the power switch is placed in the ON position,
the control panel touch keys become operative. The
fluorescent display will be either blank or indicate
that the unit has been cleaned. (See Figure 11.)
UNIT CLEANED
Figure 11
Brush Clean Counter
The Brush Clean Counter (item 9 on page 13) will
display the number of hours since the freezer was
last brush cleaned. After hour 99, it will change to a
letter and a number (example: A0, A1. . B0, B1, etc.)
Manager's Menu
The Manager's Menu is used to enter the operator
function displays. To access the Menu, touch the
center of the CONE symbol
on the control panel.
The arrow symbols, the SEL symbol and the CONE
symbol
will be lit when the ACCESS CODE
screen is displayed. (See Figure 12.)
Figure 12
In the Menu program, the arrow symbols and the
SEL symbol will function as menu keys.
UP ARROW - increases the value above the cursor
and is used to scroll upward in text displays.
DOWN ARROW - decreases the value above the
cursor and is used to scroll downward in text
displays.
SEL - advances the cursor position to the right and
is used to select menu options.
Note: The machine will continue operation in the
mode it was in when the Menu was selected.
However, the control keys will not be illuminated and
are non-functional when the Manager's Menu is
displayed.
