Model C712Important: To the Operator
Reset the SERVING COUNTER by selecting the
SEL symbol to advance to the next screen. Select
the UP arrow symbol to move t he arrow (>) to YES
and select the SEL symbol. The servings counter
will reset to zero and exit back to the Manager's
Menu. (See Figure 16.)
RESET DRAW COUNTER
YES
>NO
Figure 16
The SET CLOCK option allows the Manager to
adjust the control clock date and time. The date and
time may only be changed after the freezer has
been manually cleaned but before it has been
placed in the AUTO or STANDBY mode. The
following message will be displayed if the SET
CLOCK option i s selected when the machine is not
in a brush clean state. (See Figure 17.)
SET CLOCK
12:01 7/15/2004
NO CHANGES ALLOWED
Press Any Key
Figure 17
To change the date or time, select the SET CLOCK
option in the menu. Touch the UP arrow symbol to
advance the arrow from Exit to Change, then touch
the SEL symbol to select the Change option. (See
Figure 18.)
SET CLOCK
12:01 7/15/2004
Change
>Exit
Figure 18
Change the time by touching the UP arrow with the
cursor under the hour position. Move the cursor to
the minutes by touching the SEL symbol. Once the
correct minutes are entered, touch the SEL symbol
to advance the cursor to the month. (See Figure 19.)
SET CLOCK
12
:01 7/15/2004
>Exit
Figure 19
Enter the correct month, day, and year. Then touch
the SEL symbol to advance to the DAYLIGHT
SAVING TIME screen. (See Figure 20.)
DAYLIGHT SAVING TIME
ENABLED
> Enable
Disable
Figure 20
The Daylight Saving feature when enabled, will
automatically adjust the control clock for daylight
saving time. To Disable the Daylight Saving Time
feature, select the UP arrow to move the arrow to
Disable. Then touch the SEL symbol to save the
new setting.
The AUTO START TIME option allows the Manager
to set the time of day at which the machine
automatically enters the AUTO mode from the
STANDBY mode. The machine must be in the
STANDBY mode in order to AUTO start at the
programmable time. The AUTO START TIME can
also be Disabled and require starting the AUTO
mode manually. (See Figure 21.)
AUTO START TIME
DISABLED
Enable
> Disable
Figure 21
