Model C712 Important: To the Operator
050722
Entering Access Code
With the ACCESS CODE screen on the display use
the SEL symbol to set the first code number in the
cursor position. When the correct number is
selected, touch the SEL symbol to move the cursor
to the next number position. (See Figure 13.)
ENTER ACCESS CODE
83 0 9
__
Figure 13
Continue to enter the proper access code numbers
(8309) until all four numbers are displayed, then
touch the SEL symbol. The Manager's menu list will
display on the screen provided the correct access
code is entered.
If an incorrect number is entered for the access
code, the display will exit the Menu program when
the SEL symbol is selected. (See Figure 14.)
Figure 14
Menu Options
Touch the ARROW symbols to move up or down
through the Menu. Select a Menu option by touching
the SEL symbol. Exit the Menu program by selecting
EXIT FROM MENU or touch the CONE symbol
.
The following menu options are listed in the
Manager's Menu.
EXIT FROM MENU
RESET DRAW COUNTER
SET CLOCK
AUTO START TIME
STANDBY MODE
MIX LEVEL AUDIBLE
FAULT DESCRIPTION
FAULT HISTORY
SYSTEM INFORMATION
Selecting “EXIT FROM MENU” will exit the
Manager's Menu and the return the control panel
symbols to normal operation.
The SERVING COUNTER screen is used to check
or reset the number of servings dispensed from the
machine. The SERVING COUNTER will
automatically reset to zero when the machine is
brush cleaned. (See Figure 15.)
SERVINGS COUNTER
00
> Next
Figure 15
