PS/2 mouse function control
PS/2 mouse function control
PS/2 mouse function control
This mainboard has a built-in PS/2™ mouse port. If you are using the PS/2™
mouse, please leave this field as “Enabled”. In case you prefer to connect a serial
mouse to the serial port instead of using the PS/2™ mouse, you may choose
“Disable” in this field so that the IRQ12 can be released for other devices.
OS Select For DRAM > 64MB
OS Select For DRAM > 64MB
OS Select For DRAM > 64MB
Select OS2 only if you are running OS/2 operating system with greater than 64 MB
of RAM on your system. Otherwise, use the default setting “Non-OS2” for all other
operating systems.
HDD S.M.A.R.T Capability
HDD S.M.A.R.T Capability
HDD S.M.A.R.T Capability
If your Hard Drive support the S.M.A.R.T. technology (Self Monitoring Analysis
Reporting Technology) feature, you may “enable” this item to monitor and report
your Hard Drive healthy status. Check with your Hard Drive Vendor for further
information about SMART feature.
Note! Using this feature may decrease system performance.
Report No FDD for WIN 95
Report No FDD for WIN 95
Report No FDD for WIN 95
If you did not install a floppy drive select Yes. This will release IRQ6 for
compatibility with Windows 95 logo certification. You should also disable the
Onboard FDC Controller field in the Integrated peripherals menu.
XXXX
XXXX
XXXX
-
-
-
XXXX Shadow
XXXX Shadow
XXXX Shadow
This field allows you to enable or disable the shadow feature for the Video BIOS
and the appropriate memory segment.
SDRAM Speed Selection
SDRAM Speed Selection
SDRAM Speed Selection
The first four fields on the screen are used to adjust the SDRAM timing. Use these
fields to configure the DRAM parameter properly will give you the best
performance. Improper setting on these fields will cause instability, therefore it is
recommended to leave it to default setting.
System BIOS Cacheable
System BIOS Cacheable
System BIOS Cacheable
Select Enabled allows caching of the system BIOS ROM at F0000h-FFFFFh,
resulting in better system performance.
BIOS
BIOSBIOS
BIOS
3.5
3.5
3.5
ADVANCED CHIPSET FEATURES
ADVANCED CHIPSET FEATURES
ADVANCED CHIPSET FEATURES
(The Advanced Chipset Features Menu is on the following page)
