Setup Guide Checklist
c Chapter 1: Install Global Configurator
 • Download from www.extron.com, or
• Install from Extron Software Products CD
c Chapter 2: Make the MLC cable connections.
1. cPower
2. cLocal Area Network (LAN) – IP models only
3. cDevices
c Chapter 3: Congure MLC 104 Plus Series using Global
Configurator.
1. cDownload device drivers.
2. cCreate a new Global Congurator project le.
3. cAdd a device and (for IP models) set its IP address.
4 cDene the location of the new device.
5. cSave the new Global Congurator le.
6. cCongure e-mail server. (IP models only)
7. cCongure e-mail messages. (IP models only)
8. cConfigure contacts. (IP models only)
9. cAssign serial device drivers.
10. cAssign IR drivers.
11. cCongure the front panel.
12. cCongure associated control modules.
13. cCreate a shutdown schedule.
14. cCreate a lamp hour notication. (IP models only)
15. cCreate a disconnect notice. (IP models only)
16. cBuild the Global Configurator file.
17. cUpload the Global Congurator le.
18. cLaunch GlobalViewer. (IP models only)
19. cTest the MLC’s setup.
Back cover:
checklist and contact
information
