C2631M-C (7/09) 61
6. Click the Set button again to exit programming mode.
Figure 29. Clearing a Pattern
ACCESSING PROGRAMMING FEATURES OF REMOTE CAMERAS
You can use the PTZ function to program features of remote cameras, such as Pelco’s Spectra or Esprit
®
. Only cameras that support remote
programming through D, P, Coaxitron, or supported third-party protocols can use this feature.
The DX8100 allows you to navigate the remote camera menu system using any of the following:
• PTZ OSD Menu controls. For information about using the PTZ OSD Menu controls, refer to Using the PTZ OSD Menu Control on page 61.
• Keypad controls. For information about using the keypad controls, refer to Accessing a Remote Camera Programming Menu on page 62.
• Keyboard keys. For information about using the keyboard keys, refer to Using Keyboard Shortcuts to Operate PTZ and Lens Functions on
page 56.
DX8100This section describes how to access the programming features of remote cameras and includes the following topics:
• Using the PTZ OSD Menu Control
• Accessing a Remote Camera Programming Menu on page 62
Using the PTZ OSD Menu Control
The DX8100 allows you to navigate the menu system of remote cameras using the PTZ OSD Menu control. The PTZ OSD Menu control is
available when the DX8100 is in Live View mode. DX8100Alternative methods to navigate the remote camera menu system are as follows:
• Keypad controls. For information about using the keypad controls, refer to Accessing a Remote Camera Programming Menu on page 62.
• Keyboard keys. For information about using the keyboard keys, refer to Using Keyboard Shortcuts to Operate PTZ and Lens Functions on
page 56.
Figure 30 shows the parts of the PTZ OSD Menu control.
Figure 30. PTZ OSD Menu Control
ᕣ
ᕡ
ᕢ
ᕤ
ᕢᕡ
ᕤ
ᕣ
ᕤ
ᕣ
