4 Internal Battery (continued)
4.2 Battery Cabinet
The standard battery cabinet includes two models: BP480V26B (Figure 4.2a) and BP480V40C (Figure 4.2b). (See Table 4.2a for battery cabinet
weight and fl oor loading)
BP480V26B BP480V40C
Weight
470 kg 700 kg
Floor Loading
1064 kg/m^2 1575 kg/m^2
Battery Capacity
40 40
Voltage
12V DC 12 V DC
Amp/Hour
26AH 40AH
Battery Type
VRLA VRLA
Fig 4.2a BP480V26B
Fig 4.2b BP480V40C
Table 4.2a
