Chapter 34 Product Specifications
X6004 User’s Guide
285
The following list, which is not exhaustive, illustrates the standards supported in the X6004.
Music on Hold Specify an audio file to play for callers who are placed on hold.
G.711 format audio file (*.wav), µ-law
Distinctive Ring Specify different rings for calls based on the source of the call.
Auto Callback The X6004 can automatically call back a busy extension once it frees up.
Call Parking The X6004 allows you to put a call on hold and pick up the call again
from another location within your organization.
ZyStack Configure up to 5 X6004 to work together under a single management IP
address.
Call Detail Record The X6004 can generate call detail records and send them to a MySQL
database and the aged file (compressed file containing CDRs) can be
sent to the administrator via email.
Syslog The X6004 can generate syslog messages and send it to a syslog
server.
IVR Interactive Voice Response system allows users to edit some of their
personal (unique to their extension) settings via their handsets. For
example, users can change their voicemail and forwarding settings using
IVR.
Firmware Upgrade Download new firmware (when available) from the ZyXEL web site and
use the web configurator, CLI or an FTP tool to put it on the X6004.
Note: Only upload firmware for your specific model!
Configuration Backup &
Restoration
Make a copy of the X6004’s configuration and put it back on the X6004
later if you decide you want to revert back to an earlier configuration.
Table 135 Standards Supported
STANDARD DESCRIPTION
RFC 791 IP
RFC 793 TCP
RFC 826 Address Resolution Protocol (ARP)
RFC 867 Daytime Protocol
RFC 868 Time Protocol
RFC 894 Ethernet II Encapsulation
RFC 1305 Network Time Protocol (NTP version 3)
RFC 1889 RTP
RFC 1890 RTCP
RFC 2131, RFC 2132 Dynamic Host Configuration Protocol (DHCP)
RFC 2136 DDNS
RFC 2327 Session Description Protocol (SDP)
RFC 2833 DTMF
RFC 3164 Syslog
RFC 3261 SIP
RFC 3842 Message Waiting Indicator
Table 134 Firmware Specifications
FEATURE DESCRIPTION
