ENGLISH
SECTION 2 - INSTALLATION
Figure 2-2. MODEL BG2136 SINGLE OVEN DIMENSIONS
GAS INLET
ELECTRICAL JUNCTION BOX
RECOMMENDED MINIMUM CLEARANCES:
Rear of Oven to Wall - 6″ (150mm)
Non-control End of Oven to Wall - 0″
Control End of Oven to Wall - 0″
1
2
3
2
3
3
3
1
Figure 2-3. MODEL BG2136 DOUBLE OVEN DIMENSIONS
2
3
3
3
1
GAS INLET
ELECTRICAL JUNCTION BOX
RECOMMENDED MINIMUM CLEARANCES:
Rear of Oven to Wall - 6″ (150mm)
Non-control End of Oven to Wall - 0″
Control End of Oven to Wall - 0″
1
2
3
