OPERATING YOUR BREVILLE DUAL BOILER™OPERATING YOUR BREVILLE DUAL BOILER™
START UP
Press the POWER button to switch the
machine ON. The POWER button will flash
and the LCD screen will display the current
espresso boiler temperature.
When the machine has reached operating
temperature, the POWER button light will
stop flashing and the MANUAL, 1 CUP and
2 CUP buttons will illuminate.
The machine is now in STANDBY mode
ready for use.
NOTE
You will not be able to select 1 CUP,
2 CUP or CLEANING CYCLE during
START UP. If you select one of these
functions during START UP, the LCD
will display BUSY.
POWER SAVE MODE
The machine will enter POWER SAVE mode
after remaining idle for 1 hour and turn off
completely if not used for a continuous
4 hour period.
Pressing any button during POWER SAVE
(except POWER), or operating the STEAM
LEVER or HOT WATER dial will cause the
machine to enter START UP mode.
Pressing the POWER button during
POWER SAVE will turn the machine off.
LCD INTERFACE
Display modes
3 modes can be displayed on the LCD
screen: Shot Temp, Shot Clock or Clock.
Press UP or DOWN arrow to change the
display mode.
1. Shot Temp
Displays selected extraction temperature
(default set at 93°C).
2. Shot Clock
Displays duration of current espresso
extraction in seconds.
3. Clock
Displays current time. (default set at
12.00am if time has not been set).
GENERAL OPERATION
1 CUP
Press 1 CUP once to extract a single shot
of espresso at the pre-programmed volume
(approx. 30ml). The extraction will start
using the low pressure pre-infusion.
The machine will stop after 1 CUP volume
has been extracted and will return to
STANDBY mode.
2 CUP
Press 2 CUP button once to extract
a double shot of espresso at the pre-
programmed volume (approx. 60ml).
The extraction will start using the low
pressure pre-infusion.
The machine will stop after 2 CUP volume
has been extracted and will return to
STANDBY mode.
MANUAL
The MANUAL button allows you to
control the espresso pour volume to suit
your preference.
Press MANUAL button once to start the
espresso extraction. The extraction will
start using the low pressure pre-infusion.
Press MANUAL button again to
stop extraction.
NOTE
To stop an extraction at any time,
press the 1 CUP, 2 CUP or MANUAL
button and the machine will return to
STANDBY mode.
