Continental CP43609 Coffeemaker User Manual



11 12
GB
GB
INSTRUCTION MANUAL
EM123
ESPRESSO/CAPPUCCINO/COFFEE MACHINE
Dear customer,
Please read these Operating Instructions through carefully before
connecting your device to the mains, in order to avoid damage due to
incorrect use. Please pay particular attention to the safety information. If
you pass the device on to a third party, these Operating Instructions must
also be handed over.
ASSEMBLY
SAFETY INFORMATION
Incorrect operation and improper use can damage the appliance and
cause injury to the user.
The appliance may be used only for it’s intended purpose. No
responsibility can be taken for any possible damage caused through
incorrect use or improper handling.
Before connecting the appliance to the power source, check that the
current and power match those given on the rating plate.
Do not put the appliance or the plug in water or any other liquid.
However should the appliance accidentally fall into water, unplug the
appliance immediately and have it checked by a qualified person before
using it again. Non-observance could cause a fatal electric shock!
Never attempt to open the housing yourself.
Do not place any kind of object into the inside of the housing.
Do not use the appliance with wet hands, on a damp floor or when the
appliance itself is wet.
Do not touch the plug with wet or damp hands.
Check the cord and the plug regularly for any possible damage. If the
cord or plug is damaged, it must be replaced by the manufacturer or a
qualified person in order to avoid a hazard.
Do not use the appliance if it is dropped or otherwise damaged or if the
cord or plug are damaged. In the case of damage, take the appliance to
an electrical repair shop for examination and repair if necessary.
Never attempt to repair the appliance yourself. This could cause an
electric shock!
Do not allow the cord to hang over sharp edges and keep it well away
from hot objects and naked flames. Remove the plug from the socket
only by holding the plug.
For extra protection it is possible to fit the electric household installation
with a fault current breaker with a rated breaking current of not more
1 Espresso machine lock
2. Espresso machine water tank
3. Cover
4. Coffee machine water tank
5. Coffee filter handle
6. Coffee filter
7. Filter holder
8. Drip stop
9. Power cord storage (back side)
10. Power cord with power plug
11. Warming plate
12. Switch I O (Coffee machine)
13. Switch I O (Espresso machine)
14. Drip tray holder
15. Drip tray
16. Grid
17. Steam nozzle
0
1 5432 876
10 916 15 14 13 12 11
20
19 18 17
232221
29 28 27
262524
303132
18. Strainer and position of
espresso filter holder
19. Steam and espresso
controller
20. Espresso pot handle
21. Espresso pot cover
22. Espresso pot
23. Espresso filter holder
24. Espresso filter
25. Filter lock
26. Handle for espresso filter holder
27. Head of measuring spoon
28. Measuring spoon
29. Coffee pot handle
30. Rocker lever
31. Coffee pot cover
32. Coffee pot
GB
GB
49 50
MANUAL DE INSTRUCCIONES
EM123
CAFETERA PARA ESPRESSO / CAPPUCCINO
Estimado cliente,
Por favor lea las instrucciones de uso con atención antes de conectar su
aparato a la red eléctrica, para evitar daños que un uso no adecuado
pudiese provocar. Observe especialmente las indicaciones de seguridad.
Si cede este aparato a terceras personas, deberá entregar las
instrucciones de uso con él.
MONTAJE
INFORMACIONES DE SEGURIDAD
Una utilización incorrecta y mal uso pueden dañar el aparato y
ocasionar heridas al usuario.
Este aparato sólo puede ser destinado al uso para el que fue fabricado.
No se puede asumir responsabilidad por cualquier posible daño
causado por utilización o manejo incorrectos.
Antes de conectar el dispositivo a la toma de corriente, verificar que la
corriente y el voltaje correspondan a aquellos indicados sobre la chapa
No colocar el dispositivo o el enchufe en agua o cualquier otro liquido.
En caso de que el dispositivo caiga en agua accidentalmente,
desconectar el enchufe imediatamente y hacer verificar el aparato por
una persona cualificada antes de utilizarlo nuevamente. La no
observancia de esta regla podria causar una descarga electrica
fatal!
No ententar abrir el alojamiento sin la ayuda de un experto.
No coloque ninguna clase de objetos dentro de la carcasa.
No utilice el aparato con las manos húmedas, sobre un suelo húmedo
o cuando el aparato mismo esté mojado.
No toque el enchufe con las manos húmedas o mojadas.
Verificar el cable y el enchufe con regularidad para excluir eventuales
daños. En caso de que uno de estos dos estè dañado, tendrà que ser
substituido por el fabricante o por persona cualificada para evitar
riesgos.
No utilice el aparato si se ha caído o se ha dañado de alguna otra
1. Cierre de la cafetera exprés
(espresso)
2. Depósito de agua de la cafetera
exprés (espresso)
3. Tapa
4. Depósito de agua de la cafetera
5. Asa del filtro de café
6. Filtro de café
7. Soporte del filtro
8. Freno de goteo
9. Lugar para guardar el cable(parte
trasera)
10. Cable de alimentación con
enchufe
11. Plato para conservar la
temperatura
12. Interruptor I O (Máquina de café)
13. Interruptor I O (Máquina de café
exprés)
14. Soporte para la bandeja de goteo
15. Bandeja de goteo
16. Rejilla
0
1 5432 876
10 916 15 14 13 12 11
20
19 18 17
232221
29 28 27
262524
303132
17. Boquilla de vapor
18. Colador y punto de soporte
del filtro exprés (espresso)
19. Control de vapor y del
exprés (espresso)
20. Asa de la cafetera exprés
(espresso)
21. Cubierta de la cafetera
exprés (espresso)
22. Cafetera exprés (espresso)
23. Soporte del filtro exprés
(espresso)
24. Filtro exprés (espresso)
25. Fijación del filtro
26. Asa para el soporte del filtro
exprés (espresso)
27. Extremo de la cuchara de medir
28. Cuchara de medir
29. Asa de la cafetera
30. Palanca
31. Tapa de la cafetera
32. Cafetera
