2-11
ITEM PART # COMPONENT
Complete Box Assemblies
100-120V (Domestic)
106-4117 Full-vat
106-4121 Dual-vat
120V (Domestic)
106-4118 Full-vat
106-4122 Dual-vat
208-240V (Domestic)
106-4119 Full-vat
106-4123 Dual-vat
208-250V (Export)
106-4120 Full-vat
106-4124 Dual-vat
Components
1 200-6970 Component Box
2 200-6855 Bracket, Component Box Gap
3 200-6956 Cover, Component Box Hole
4 810-0045 Bushing, .875”
5 810-1164 Terminal Block, 1 Plc. Screwless Terminal
6 810-1168 Terminal Block, Screwless End
7 816-0217 Insulating Paper
Wiring
* WIR0162 Component Shield Wiring (FV, DV)
* WIR0349 Microswitch Wiring (DV)
* WIR0350 Microswitch Wiring (DV)
8 Transformers
807-2176 100-120V/12V & 24V
807-0855 120V/12V
807-0800 120V/24V
807-0680 208-240V/24V
807-1999 208-250V/12V & 24V
9 826-1365 Screw, 6-32 x ⅜ Trussed Slotted Head (pkg. of 25)
10 826-1359 Screw, 4-40 x ¾ Pan Slotted Head (pkg. of 25)
11 809-0360 Screw, #8 x ⅜ Type B Hex Washer
12 826-1366 Nut, 4-40 Hex Keps with External Tooth (pkg. of 25)
13 809-0250 Nut, 6-32 Hex Keps
* Not illustrated.
** See Section 2.17 for thermostats, timers, and associated knobs.
