2-17
ITEM PART # COMPONENT
Complete Box Assemblies
106-4064
Full-vat, 120V (Domestic; Shield Assembly 106-4075)
106-4065
Full-vat, 208-240V (Domestic; Shield Assembly 106-4076)
106-4066
Full-vat, 208-250V (Export; Shield Assembly 106-4077)
Components
1 106-4088 Component Stud
2 826-1337 Tab, Terminal (pkg. of 5)
3 807-4037 Ignition Module, Domestic (240V and below)
4 807-2971 Ignition Module, Export (208-250V)
5 806-5857 PC Board Assembly
6 810-0045 Bushing, .875
7 807-0670 Relay, 24V
8 200-7176 Bracket, Relay
9 810-1164 Terminal Block, 1 Plc. Screwless
10 816-0217 Insulating Paper
* WIR0258 Wiring, Component Shield
11 809-0349 Spacer, Interface Board
12 826-1346 Spacer, Ignition Module (pkg. of 10)
13 Transformers
807-2176 100-120V/12V & 24V
807-1999 208-240V/24V, 208-250V/12V & 24V
14 200-6855 Bracket, Component Box Gap
15 809-0328 Screw, 4-40 x ¼ Pan Slotted Head
16 809-0247 Nut, 8-32 Hex Keps
17 809-0164 Screw, #8 x 1 Hex Washer Slotted Head
18 809-0102 Screw, 8-32 x ⅜ Trussed Slotted Head
19 826-1359 Screw, 4-40 x ¾ Pan Slotted Head (pkg. of 25)
20 809-0360 Screw, #8 x ⅜ Type B Hex Washer
21 826-1366 Nut, 4-40 Hex Keps with External Tooth (pkg. of 25)
22 809-0250 Nut, 6-32 Hex Keps
23 200-6956
Cover, Component Box Hole (see illustration on Page 2-10)
* 806-5879SP Cable Assembly, Ignition Module
* 807-3483
Cable, Ignition (used with MJ45 ignition cable kit, 826-1721)
* 806-5830 Cable Assembly, Ignition
* 807-1928 Flame Sensor Electrode
* 807-3484 Connector, Rajah
* Not illustrated.
