2-29
2.11 Filter Pan Assembly
7
2
6
5
1
4
3
8
9
10
11
14
12
13
ITEM PART # COMPONENT
106-3796SP
Pan Assembly, Complete (Includes 823-4532)
1 823-4532SP Filter Pan
2 810-2743 Crumb Tray
* 813-0568 Plug, ⅛” Socket-head Pipe
3 826-1372 Nut, Grip ¼-20 Hex (pkg. of 10)
* 816-0596 O-ring
4 810-2198 Roller, Filter Pan Rail
* 810-2012 Rail Set, Filter Pan Rail
* 826-1979 Kit, Filter Pan Roller
* 809-0191 Washer, Spring Lock, ¼”
Other Filter Components
5 200-2124 Screen, Sana Grid
6 810-2798 Ring, Hold Down
7 823-5291
Lid, Filter Pan (included in kit 826-2109, 826-2110, and 826-2111)
8 823-5292
Splash Shield (included in kit 826-2109, 826-2110, and 826-2111)
9 106-5141 Bracket, Shield Mounting (MJ35)
10 809-0173
Clip, Tinnerman (included in kits 826-2109, 826-2110, and 826-2111)
11 200-9732
Lip, Suction Fitting (included in kits 826-2109, 826-2110, and 826-2111)
12 200-9715
Brace, Drain Spout (included in kits 826-2110 and 826-2111)
14 826-1371 Screw, #8 x ½” Hex Head Drill Point (pkg. of 25)
13 809-0785 Screw, #14 x ¾” Slotted Head
* 824-0430 Crumb Screen
* 806-3177 Cover, Filter Cabinet
* 200-6310 Support, Rear Pan Rail
* 809-0743 Screw, 4-40 x 1 Pan Head, Stainless Steel
* 803-0170 Filter Paper, 16.5 x 25.75 (box of 100 sheets)
* 803-0002 Filter Powder (box of 80 individual packs)
* Not illustrated.
