Installation Instructions
REPLACING THE FREEZER DRAWERS (cont.)
ATTACH AND SECURE THE DRAWER
FRONT TO THE SLIDES
Pull out the rail assemblies to the full length on
each side of the cabinet.
Drive the top screw into the door on each side
until it is 1/2 way in.
Hang the drawer front onto open slots on
the slides.
1
A
B
REPLACE THE FREEZER BASKET
Replace the bottom drawer freezer basket by
lowering it into the frame (see page 10).
2
Two people may be required to complete
this procedure.
Screw
Slot
C
26
BOTTOM DRAWER
ATTACH AND SECURE THE DRAWER
FRONT TO THE SLIDES
(CONT.)
Drive screws fully. (There are 10 screws,
5 on each side.)
1
D
Step D2:
Drive
screws in
these
holes.
Step D1:
Line up
screw hole
in freezer
drawer and
drive fully.
