G. Final Checklist
WARNING
CHOKING HAZARD: Ensure all components, fasteners, and thumbscrews are
securely in place after installation. Make sure that none have fallen into the
storage bin.
1) Is the icemaker level?
) Is the icemaker in a site where the ambient temperature is within 45°F to 100°F (7°C to
38°C) and the water temperature within 45°F to 90°F (7°C to 3°C) all year around?
3) Is there at least 6" (15 cm) clearance at rear and left side, 10" (5 cm) at right side, and
0" (51 cm) at top for proper air circulation and ease of maintenance and/or service
should they be required?
4) Have the shipping carton, tape, and packing material been removed from the icemaker?
5) Have all electrical, water supply, and drain connections been made? Do electrical,
water supply, and drain connections meet all national, state, and local code and
regulation requirements?
6) Has the power supply voltage been checked or tested against the nameplate rating? Is
the power supply a properly grounded, independent wall outlet?
7) Are the water supply line shut-off valve and drain valve installed? Has the water
supply pressure been checked to ensure a minimum of 10 PSIG and a maximum of
113 PSIG?
8) Are all components, fasteners, and thumbscrews securely in place?
9) If the icemaker is on a stand, has it been secured to the stand as outlined in the stand's
installation instructions? If the icemaker is mounted at to a counter, has the perimeter
where the icemaker contacts the counter been sealed with approved caulk compound?
10) Are the compressor hold-down bolts snug? Have the refrigerant lines been checked to
make sure they do not rub or touch other lines or surfaces?
11) Has the end user been given this instruction manual, and instructed on how to operate
the icemaker and the importance of the recommended periodic maintenance?
1) Has the end user been given the name and telephone number of an authorized service
agent?
13) Has the warranty card been lled out and forwarded to the factory for warranty
registration?
