Cornelius IWC322 Ice Maker User Manual



7
166240004
12/1/94
Rev 3/4/96
SPECIFICATIONS 50 HZ
MODEL
IAC322E50
IAC330E50
IACS277E50
IWC322E50
IWC330E50
IWCS227E50
IAC522E50
IAC522E50L
IAC530E50
IAC530E50L
IWC522E50
IWC522E50L
IWC530E50
IWC530E50L
UNIT
Volts 220 220 220 220
Phase 1 1 1 1
Hertz 50 50 50 50
No. Wires 2+ground 2+ground 2+ground 2+ground
MIN. CIRCUIT
Amps 15 15 15 15
MAX FUSE SIZE (HVAC CIRCUIT BREAKER REQUIRED)
Amps 15 15 15 15
REFRIGERANT
Type R404A(HP62) R404A(HP62) R404A(HP62) R404A(HP 62)
Weight (oz) 17 15 26 23
Weight (g) 482 425 737 652
COMPRESSOR
Volts 220 220 220 220
Phase 1 1 1 1
Hertz 50 50 50 50
LRA 26 26 33 33
RLA 5.3 5.3 8.2 8.2
CONDENSER FAN MOTOR (Air-Cooled Systems only) or
AIR CIRCULATION FAN MOTOR (Water-Cooled and Remote Systems only)
Volts 220 220 220 220
Phase 1 1 1 1
Hertz 50 50 50 50
Amps Running 0.75 0.3 0.75 0.3
Watts 50 6 50 6
WATER PUMP
Volts 220 220 220 220
Phase 1 1 1 1
Hertz 50 50 50 50
Amps Running 0.5 0.5 0.5 0.5
HP 1/30 1/30 1/30 1/30
