AJ-64 Conveyor Series Technical Manual 7610-003-30-93
Issued: 05-02-2006 Revised: N/A
SECTION 5: PARTS SECTION
86
MOTOR ASSEMBLIES
WASH MOTOR CHART
V
olts Phase Hz Part Number
208 - 230 1 60 06105-021-70-57
200 - 230 3 60 06105-121-70-58
460 3 60 06105-121-70-58
PREWASH MOTOR CHART
Model(s)
Volts Phase
Hz Part Number
AJ-86’s 208 1 60 06105-121-70-55
230 1 60 06105-121-70-55
208 3 60 06105-121-70-56
230 3 60 06105-121-70-56
460 3 60 06105-121-70-56
AJ-100’s 208 1 60 06105-121-70-57
230 1 60 06105-121-70-57
208 3 60 06105-121-70-58
230 3 60 06105-121-70-58
460 3 60 06105-121-70-58
POWER RINSE MOT
OR CHART
Model(s) Volts Phase Hz Part Number
AJ-100’s 208 1 60 06105-121-70-57
230 1 60 06105-121-70-57
208 3 60 06105-121-70-58
230 3 60 06105-121-70-58
460 3 60 06105-121-70-58
See Motor
Chart Below
Key, 3/16” x 1” Long
05700-011-89-17
Pump Plate
05700-021-71-83
Cap Screw, 3/8”-16 x 2”
05305-011-74-98
Wash Impeller
05700-031-67-45
Power Rinse Impeller (AJ-100’s)
05700-031-67-45
Prewash Impeller (AJ-86’s & AJ-100’s)
05700-031-71-78
Pump Seal
05330-011-71-98
Impellar Washer
05700-011-71-95
Bolt, 1/4”-20 x 3/4”
05305-274-04-00
Upper Support Bracket
05700-021-73-68
Lower Support Bracket
05700-021-73-71
Nut, 1/4”-20 Serrated
05310-011-66-49
Motor Mounting Gasket
05330-011-71-62
Clamp
(Not Shown)
04730-002-32-15
