AJ-64 Conveyor Series Technical Manual 7610-003-30-93
Issued: 05-02-2006 Revised: N/A
SECTION 5: PARTS SECTION
110
D226 STEAM BOOSTER PLUMBING ASSEMBLY (CONTINUED)
ITEM QTY DESCRIPTION Mfg. No.
1 1 Water Pressure Regulator, 3/4” 04820-100-01-06
2 2 Nipple, Brass, 3/4” NPT x 6” Long 05700-001-26-74
3 2 U-Bolt, 6”, 5/8”-11 Thread 05306-458-01-04
4 1 Platform Weldment 05700-002-78-02
5 1 Heat Exchanger 04420-100-01-05
6 1 Steam Trap, 3/4” 06680-500-02-77
7 1 Bushing, 2” NPT x 3/4” NPT, Black Iron 04730-902-06-34
8 2 Elbow, 3/4” NPT, Brass 04730-206-13-00
9 6 Nipple, 1” NPT, Close, Black Iron 04730-907-08-34
10 2 Union, 3/4” NPT, Brass 04730-212-05-00
11 2 Bushing, 2” NPT x 3/4” NPT, Brass 04730-202-18-00
12 4 Nipple, 3/4” NPT x 1-3/8” Long 04730-207-34-00
13 1 Bushing, Hex 3/4” M x 1/2” F, Brass 04730-002-56-27
14 1 Y-Strainer, 1” NPT, Black Iron 04730-217-02-32
15 2 Pressure Gauge 06685-111-88-34
16 1 Steam Relief Valve 04820-100-07-06
17 2 Nipple, 3/4” NPT x 4” Long, Brass 04730-207-05-00
18 2 Tee, 3/4” NPT x 3/4” NPT x 3/4” NPT, Brass 04730-211-01-34
19 1 Bushing, 2” NPT x 1” NPT, Black Iron 04730-002-94-51
20 3 Elbow, 90°, 1” NPT, Black Iron 04730-906-03-34
21 2 Nipple, 1” NPT x 4” Long, Black Iron 04730-907-09-34
22 1 Elbow, 90°, Street, 3/4” NPT, Black Iron 04730-011-87-37
23 1 Nipple, Pigtail, 1/4” NPT 04730-907-14-34
24 1 Coupling, 1/4” NPT x 1/4” NPT 04730-904-01-34
25 1 Steam Solenoid Valve, 240VA 04820-100-29-34
25 1 Steam Solenoid Valve, 200VA 04820-002-93-66
25 1 Steam Solenoid Valve (ASCO) 04820-002-90-26
26 1 Tee, 3/4” NPT x 3/4” NPT x 1/4” NPT, Brass 04730-211-04-00
27 1 Valve, Test Cock, 1/4” NPT 04810-011-72-67
28 1 Tee, 1” NPT x 1” NPT x 1” NPT, Black Iron 04730-911-01-34
29 1 Valve, Safety Relief 1” NPT 04820-100-01-35
30 1 Tee, 1” NPT x 1” NPT x 1/4” NPT, Black Iron 04730-911-01-00
31 2 Union, 3/4” NPT, Black Iron 04730-912-01-00
32 2 Nipple, 3/4” NPT x 2” Long, Brass 04730-207-46-00
33 2 Nipple, 3/4” NPT, Close, Black Iron 04730-907-01-00
